Kaisai KHC-12RY3 - 9.3.4 Controls parts for backup heater

9.3.4 Controls parts for backup heater
1-phase 6kW with backup heater(1-phase 3kW)
1
24
3
34
2
1
Auto thermal protector
Manu thermal protector
Backup heater contactor KM1
Backup heater contactor KM2
Code
Assembly unit
Code
Assembly unit
1
2
3
4
5
Backup heater contactor KM3
1
24
3
5
1-phase 8-10kW with backup heater(1-phase 3kW units RY1) 3-phase 8-16kW with backup heater(3-phase 9kW units RY3)
