Kaisai KHC-12RY3 - Page 92

8/10/12/14/16 kW
8/10/12/14/16 kW
6 kW
Please remove the hollow
plate after installation.
6 kW
Internal layout:12~16kW(3-phase) for example
Electric Control System
Terminal Block
Hydraulic System
Refrigerant System
The picture and function described in this manual contain the backup heater components.
Pictures in this manual are for reference only, please refer to the actual product.
NOTE
12/14/16 kW
Remove the
transportation support
Capacity of
backup
heater
3 kW (1-phase)
Backup heater (standard)
9 kW (3-phase)
Unit
1-phase 3-phase
6 RY1
8 RY3
16 RY312 RY3 14 RY3
10 RY3
8 RY1
10 RY1
