Kaiweets KM601s - Current Measurements; Ampere (A) Current Measurement; mA Current Measurement

Ampere (A) current measurement
1. Insert the red probe into the ‘A’ jack and the black probe into the ‘COM’ jack. The Meter will
automatically adjust to the ‘A’ gear. ‘DC’ signal and ‘A’ signal will be displayed on the screen,
indicating DC current measurement.
2. Press the ‘%] button, ‘A’ signal and ‘AC’ signal will be displayed on the screen, indicating of
AC current measurement.
NOTE:
1. When measuring AC current, the frequency will be displayed, and when measuring DC current,
the ambient temperature will be displayed on the screen.
2. ‘LEAD’ signal will be displayed on the screen and the indicator light will turn red when the test
leads are connected incorrectly, please insert the red test lead into ‘A’ jack.
3. The meter will turn on the current testing function when you insert the red test lead into ‘A’
Jack and the black test lead into ‘COM jack in any mode. For safety, users cannot press the “Ame”
button to switch the functions.
4. The meter will beep regularly to remind users to use the current testing function correctly. Do
not measure current >10A in this gear, in case of the 10A fuse burnt.
mA current measurement
1. Insert the red probe into the ‘mA’ jack and the black probe into the ‘COM’ jack. The meter will
automatically adjust to the A’ gear. ‘DC’ signal and ‘mA’ signal will be displayed on the screen,
18
