kala Mistral 1650 User Manual

16
6.4 b) Lamination with waste paper, double side adhesive, or direct lamination of a print roll.
Install the upper film as described above.
Install the waste paper, double side adhesive, or print roll on a blocking shaft on position 3 and
centre it with the graduation..
Align this media in regards with the lamination film. Help yourself with the graduations on the
shafts. Double side adhesive should go directly to the lamination film bypassing the separation bar.
Once aligned, stick this media onto the lamination film
Lock the self blocking shaft on the lower position with the locker on the right of the machine.
Take the feeding tray down in working position. Place the feeding plate between the lamination
roller.

kala Mistral 1650 Specifications

General

Brand	kala
Model	Mistral 1650
Category	Laminator
Language	English
