SPECIFICATIONS
2
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited by
circuit breakers.
The optimum operating conditions are ambient temperature of 17–25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specifications. In case of deviations from the above ambient values, the
performance of the generator can be different.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80% of the
rated power.
Model KSB 1200C KSB 2200A KSB 2200C KSB 2800A
Voltage, V 230
Maximum power, kW 1,0 2,2 2,2 2,8
Rated power, kW 0,9 2,0 2,0 2,5
Frequency, Hz 50
Current max, A 4,35 9,57 9,57 12,17
Outlets 1*16А 2*16А 2*16А 2*16А
Fuel tank capacity, L 6 12 12 12
Voltmeter +
Noise level Lpa(7m)/Lwa, dB 70/95 70/95 70/95 71/96
Output 12 V, A 12/8,3
Engine model KSB 90 KSB 220 KSB 220 KSB 220
Engine type Gasoline powered four-stroke
Power output (hp) 2,9 7 7 7
Crankcase capacity, cm
3
0,37 0,6 0,6 0,6
Engine capacity, cm
3
80 210 210 210
Voltage regulator AVR
Engine start manual
Power factor, cosφ 1
Dimensions (LxWxH), mm 470x365x380 605x440x435 605x440x435 605x440x435
Net weight, kg 26 33,2 33,2 36,2
Protection class IP23M
Max. altitude above sea level, m 1000
Relative humidity <95%
Rated voltage tolerance – max. 5%
