INSTALLATION MANUAL / USER MANUAL
REMOTE CONTROL PANELS RC200 / RC200 NVG
PAGE: 12
OCT 03/2013
3. RESET & TEST is used either to stop the ELT transmission if
activated or to perform a self-test.
Figure 9: 3-position switch
As required by regulations, the OFF mode is not available on the remote
control panel (RTCA DO 204 § 2.2.6.c, EUROCAE ED 62 § 2.5.1.1) but
directly on the ELT itself by switching it in OFF position.
Important notice: TEST/RESET (downwards) is a momentary
position.
Refer to operation manuals of the ELTs for precise information on these
modes.
(2) Monitoring
Monitoring is done through a visual indicator (Refer to Figure 8: RCP
controls, page 11) operating in the same way than those of the ELT:
Transmission:
• 1 short flash every 0.5 or 0.7 seconds during homer transmission;
• 1 long flash during ELT transmission on 406 MHz.
Self-test:
(Refer to C. RESET & TEST, page 13).
Refer to operation manuals of the ELTs for precise information on these
modes.
