Kanto YU5 - Input Select; Front & Rear Panels

Front & Rear Panels
FRONT PANEL
1 1” Silk Dome Tweeter
2 5.25” Kevlar Mid/Woofer Driver
3 LED
Blue - Power on / Playback Mode
Yellow - Standby (solid)
- Mute (flashing)
White - Discover Mode (flashing)
- Paired (solid)
4 Volume / Input Select Knob
REAR PANEL
5 RCA L/R Input
6 3.5 mm Stereo Mini-Jack AUX Input
7 Subwoofer Output
8 Optical 1 and Optical 2 Inputs
9 Right Channel Output Terminals
(+ and −) for Passive Speaker
Connection
10 USB Charge Port (5 V 2.1A)
11 ON / OFF Switch
12 AC Input Connection (100 V - 240 V)
2
3
4
6
5
7
8
9
10
11
12
1
4
YU5’s volume knob functions as an input
select knob as well.
Push the knob to select an input source
- it cycles through the following inputs
depending on what input source was last
used.
RCA AUX OPT1 OPT2 BLUETOOTH
Volume/Input Select Knob
