Kanto YU5 - Connecting Audio Sources

7
Supporting your digital lifestyle
™
Connecting Audio Sources
RCA & 3.5 mm Stereo Mini-Jack AUX Connection
YU5 features a high quality DAC (digital-to-analog converter) that supports data streams up to
24-bit/192 kHz resolution.
YU5 supports Bluetooth 4.0 with aptX CODEC technology.
Use the appropriate audio cable to connect your audio source components to your speakers.
Refer to the following diagrams on connectivity options.
• 3.5 mm stereo mini-jack AUX cable
• Stereo RCA to 3.5 mm stereo mini-jack ‘Y’ cable
• Optical Toslink cable
PHONO PRE-AMP
TURNTABLE
LAPTOP
MP3
AUDIO
IN
OUT
CD / DVD
MP3 DOCK
R
3.5mm
L
R
L
(if necessary)*
ATTENTION
*Some models of turntables include a built-in Phono Pre-Amp.
