Kaon KSTB2020 Installation Guide

KSTB2020
User Guide
3
RJ45:
10/00 Ethernet port used to
connect to a home router
HDMI:
Digital A/V output, used to
connect to a TV via HDMI cable
AV Out:
Analog A/V output, used
to connect to a TV with no
HDMI input, connect via RCA
composite breakout cable
S/PDIF:
Audio output, used to connect
to external speakers. An optical
cable with TOSLINK connectors
is required (not included)
12V/1.5A In:
DC Power port, used to
connect via the power adapter
4
5
6
7
8
USB:
This port has an output
power capability of 5V DC
@ 1 amp
9
4 5 6 7 8 9
Rear View Side View

Kaon KSTB2020 Specifications

General

Brand	Kaon
Model	KSTB2020
Category	Set-top boxes
Language	English
