KAP ROiK-10 - Page 12

[ANDROID NAVIGATION]
ROiK-10
CABLE CONNECTION – Interface Capacitive Touch
Use Capacitive Touch
(Goodix GT9xx)
※ Digital LVDS OUT/CVBS OUT
DIP S/W 1 = OFF
CAP TOUCH EXT
※ Capacitive Touch
DIP S/W 1 = ON
1 2
ON
3 4
ANDROID
NAVIGATION
POWER UART LVDS OUT RGB OUT AV IN/OUT SW GPS WIFI/BT
DEBUG
MODE SW
R-KEY USB3.0 T-KEY HDMI OUT USB2 USB1 MicroSD
DIGITAL LVDS
INTERFACE
LVDS IN
RGB
INTERFACE
RGB IN
Capacitive
Touch Panel
CAP
TOUCH
1 2
ON
1 2
ON
※ RGB OUT
DIP S/W 1 = ON
OR
