Getting started
- 4 -
3 . Connection panel
The connection panel serves as a link between the PC and the console and, besides this, it
connects the console to various peripherals, if needed.
The link to the PC is via a conection to an USB cable through A and the link with periphe-
rals is through cable B.
Figure 3: Connection panel
1 - Peripheral connector
2 - USB PC Connector
A
B
Memory Reader
Multi/FF/EVO Remote control PC
