Kärcher BR 40/10 C Adv User Manual

- 5
Fault Remedy
Appliance cannot be started Check if the mains plug is connected.
Socket fuse rating too low, look for proper socket.
Insufficient water quantity Check fresh water level, refill tank if necessary.
Clean the ball valve in the fresh water reservoir.
Check and ensure that the fresh water reservoir is seated properly on the appliance.
Filter in the fresh water reservoir is plugged, clean filter.
Check hoses for blockages; clean if required.
Insufficient vacuum performance Empty the wastewater reservoir.
Check and ensure that the fresh water reservoir is seated properly on the wastewater reservoir.
Check seals on the fresh water reservoir, clean if necessary.
Clean the seals between the appliance and the dirt water reservoir and check for tightness, re-
place if required.
Clean the fluff filter.
Clean the vacuum lips on the vacuum bar, replace if required
Suction channel plugged, clean.
Check if the vacuum bar is plugged, remove plug if required
Insufficient cleaning result Increase brush contact pressure.
Check the brushes for wear, replace if required.
Use brush rollers suited for the type of dirt and floor covering.
Brushes do not turn Check if foreign matters block the brushes; remove foreign matter if required.
Reduce contact pressure.
Overcurrent protective switch was triggered. The overcurrent protective switch will allow the op-
eration after max. one minute.
Appliance vibrates. Brush rollers are deformed because they were not unloaded by tilting the slider vertically when
parking the appliance; replace brush rollers.
Specifications
1.783-300.0
1.783-302.0
1.783-303.0
Power
Nominal voltage V/Hz 220...240 / 1~50 230 / 1~60
Average power consumption W 1900
Suction engine output W 500
Brush engine output W 2100
Maximum allowed net impedance Ohm 0.255+j0.159 0,256+j0,160
Extension cable 10 m mm
2
1,5
Extension cord 30 m mm
2
2,5
Vacuuming
Cleaning power, air quantity l/s 20
Cleaning power, negative pressure kPa 10
Cleaning brushes
Working width mm 400
Brush diameter mm 96
Brush speed 1/min 1100 1350
Dimensions and weights
Theoretical surface cleaning performance m²/h 400
Fresh/dirt water reservoir volume l 10
Length (without pushing handle) mm 520
Width (without vacuum bar) mm 470
Height (without pushing handle) mm 380
Weight (without tank content), Classic / Adv kg 33 / 34,5 34,5
Values determined as per EN 60335-2-67
Hand-arm vibration value m/s
2
<2,5
Uncertainty K m/s
2
0,2
Sound pressure level L
pA
dB(A) 74
Uncertainty K
pA
dB(A) 1
Sound pressure level L
WA
dB(A) 87
Uncertainty K
WA
dB(A) 1
13EN

Kärcher BR 40/10 C Adv Specifications

General

AC input voltage	230 V
AC input frequency	60 Hz
Maximum input power	2300 W
Maximum area performance	400 m²/h
Fresh water tank capacity	10 L
Brush rotation speed (min)	1100 RPM
Practical area performance	300 m²/h
Brush contact pressure (max)	200 g/cm²
Brush contact pressure (min)	100 g/cm²

Weight and Dimensions

Depth	470 mm
Width	520 mm
Height	380 mm
Weight	30000 g
