4
15 Elec. connecting cables
16 Water connection with strainer
17 High-pressure connection
18 Hand-held spray gun with
high-pressure hose
19 Spray lance
20 High-pressure nozzle
21 Appliance switch
22 Thermostat
23 Fuel indicator light
24 Engine indicator light
25 Liquid softener indicator light
26 Manometer
27 Detergent metering valve
1 Filling orifice for fuel
2 Handle
3 Instrument panel
4 Button for overcurrent protective relay
5 Compartment for accessories
6 Short-time operation instructions
7 Cover flap for compartment
8 Appliance hood
9 Cover flap for filling orifices
10 Filling orifice for liquid softener
11 Filling orifice for detergent
12 Recessed grips in the bottom pan
13 Pressure and volume control
14 Guide roller with parking brake
1. Diagram of the appliance
2. Controls
