Kärcher HDS 945 - Technical Data

5
3. Technical Data
HDS
945
HDS
1000
HDS
1055
Power connection
Voltage 240 240 240 V
Type of current 1~ 60 1~ 60 1~ 60 Hz
Connected load 8 9.5 9.5 hp
Mains fuse (slow) 30 30 30 A
Water connection
Supply temperature (max.) 86 86 86 °F
Supply rate (min.) 5 6 5 gpm
Suction height fom open tank at a water temp. of 86 °F 0.5 0.5 0.5 m
Performance data
Operating pressure 4602000 460-2250 4603000 psi
Flow rate 2  4 2.4  4.5 2  3.5 gpm
Operating temperature (max.) 285/175 285/175 285/175 °F
Detergent intake 0  0.25 0  0.25 0  0.25 gpm
Burner capacity 85 92 72 hp
Recoil force of spray gun at operating pressure (max.) 30 32 32 N
Sound pressure level (EN 60704-1) 79 79 79 dB(A)
Dimensions
Length 1285 1285 1285 mm
Width 690 690 690 mm
Height 835 835 835 mm
Weight without accessories 120 120 120 kg
Fuel tank (EL fuel oil or diesel) 25 25 25 l
Detergent tank 20 20 20 l
Pump oil 15W40 (Order-No. 6.288-050) 0.6 0.6 0.6 l
