English HDS Super, HDS 655, HDS 695 S, HDS 895 S, HDS 1195 24
DISCONTINUATION OF USAGE
In the event of lengthy periods of non-use or if
frost-free storage is not possible:
– Drain off water and flush out equipment with
antifreeze
– Drain cleaning fluid tank
Drain off water
– Unscrew water supply hose and high-
pressure hose
– Unscrew supply line at boiler base and allow
heating coil to drain
– Run unit for max. 1 min until pump and lines
are empty
Flushing unit with anti-freeze
– Fill the float tank with a commercially
available antifreezing compound
– Swith the unit on (without the burner) until it is
thoroughly purged
– Observe handling instructions of antifreeze
manufacturer
– By this means, a certain degree of corrosion
protection is achieved
MAINTENANCE
* Disconnect unit from mains before carrying
out any maintenance or repair work.
* Always use genuine spare parts
Shut off unit before performing any work, refer
to AFTER USE.
– Set the unit switch (item 23) to "0"
– Pull power plug out of socket
– Shut off water supply
– Actuate handgun to depressurise unit.
– Detach water connection
– Allow unit to cool down
Please consult your Kärcher dealer for
details of regular safety
inspection/maintenance agreement
Maintenance intervals
Once a week
– Clean strainer in water connection
– Check oil level
Contact Kärcher AFTER-SALES SERVICE
immediately if oil is opaque!
Once a month
– Clean strainer in low water protection
– Clean filter at cleaning-agent suction hose
After 500 hours of operation, at least once a
year
– Change oil
MAINTENANCE TASKS
Cleaning strainer in water connection
Figure 10
– Remove strainer
– Clean in water and re-insert
Cleaning strainer in low water protection
Figure 11
– Unfasten union nut and detach hose
Figure 12
– Take out strainer
If necessary, screw in bolt M8 approx. 5mm to
pull out strainer.
– Clean strainer in water
– Slide in strainer
– Mount hose
– Tighten union nut
Cleaning filter at cleaning-agent suction
hose
Figure 13
– Pull the cleaning agent suction inlet pipe out
– Clean filter in water and re-insert
