English HDS Super, HDS 655, HDS 695 S, HDS 895 S, HDS 1195 27
Technical data
Type HDS Super (1.025) HDS 655 (1.026)
Mains connection 400 V
3~ 50 Hz
230 V
3~ 50 Hz
230 V
3~ 60 Hz
230 V
1~ 50 Hz
230 V
1~ 60 Hz
Connected load 6,4 kW 6,4 kW 6,4 kW 3,2 kW 3,2 kW
Fuse (slow blow) 16 A 25 A 25 A 16 A 16 A
Water connection
Supply temperature max. 30 °C max. 30 °C
Supply volume min. 1200 l/h (20 l/min) min. 1000 l/h (16,7 l/min)
Suction height when drawn
from open tank (at 20°C water temperature) 0,5 m 0,5 m
Performance data
Flow rate: cold/hot water 450-900 l/h (7,5-15 l/min) 350-700 l/h (5,8-11,7 l/min)
Operating pressure: cold/hot water (with standard nozzle supplied) 3-18 MPa (30-180 bar) 3-11 MPa (30-110 bar)
Flow rate: steam 400 l/h (6,7 l/min) 350 l/h (5,8 l/min)
Operating pressure: steam (with steam nozzle 4.766-023) max. 3,2 MPa (32 bar) max. 3,2 MPa (32 bar)
Operating temperature
- Hot water max. 90 °C max. 90 °C
- Steam 98-155 °C 98-155 °C
Cleaning-agent intake 0 - 35 l/h (0-0,6 l/min) 0 - 35 l/h (0-0,6 l/min)
Burner output 62 kW 57 kW
Recoil force of
handgun 32 N 24 N
Noise emission
Sound level (EN 60704-1) 79 dB (A) 70 dB (A)
Guaranteed noise level (2000/14/EC) 96 dB (A) 87 dB (A)
Machine vibration
Rated vibration value (ISO 5349)
Handgun 2,6 m/s² 2,0 m/s²
Spray lance 2,3 m/s² 2,2 m/s²
Fuels
Fuel Fuel oil EL or diesel Fuel oil EL or diesel
Oil quantity 0,6 l 0,75 l
Oil grade Hypoid SAE90 (6.288-016) Engine oil 15W40 (6.288-050.0)
Dimensions and weights
Length x Width x Height 1285x690x835 mm 1285x690x835 mm
Weight not incl. accessories 133 kg 130 kg
Fuel tank 25 l 25 l
Cleaning-agent tank 20 l 20 l
