English HDS Super, HDS 655, HDS 695 S, HDS 895 S, HDS 1195 29
Type HDS 1195 (1.028)
Mains connection 400 V
3~ 50 Hz
230 V
3~ 50 Hz
230 V
3~ 60 Hz
380 V
3~ 50 Hz
Connected load 8,2 kW 8,2 kW 8,2 kW 8,2 kW
Fuse (slow blow) 16 A 35 A 35 A 16 A
Water connection
Supply temperature max. 30 °C
Supply volume min. 1500 l/h (25 l/min)
Suction height when drawn
from open tank (at 20°C water temperature) 0,5 m
Performance data
Flow rate: cold/hot water 600-1200 l/h (10-20 l/min)
Operating pressure: cold/hot water (with standard nozzle supplied) 3-18 MPa (30-180 bar)
Flow rate: steam 600 l/h (10 l/min)
Operating pressure: steam (with steam nozzle 4.766-024) max. 3,2 MPa (32 bar)
Operating temperature
- Hot water max. 90 °C
- Steam 98-155 °C
Cleaning-agent intake 0 - 48 l/h (0-0,8 l/min)
Burner output 92 kW
Recoil force of
handgun 60 N
Noise emission
Sound level (EN 60704-1) 76 dB (A)
Guaranteed noise level (2000/14/EC) 93 dB (A)
Machine vibration
Rated vibration value (ISO 5349)
Handgun 2,5 m/s²
Spray lance 2,3 m/s²
Fuels
Fuel Fuel oil EL or diesel
Oil quantity 0,75 l
Oil grade Hypoid SAE90 (6.288-016)
Dimensions and weights
Length x Width x Height 1285x690x875 mm
Weight not incl. accessories 155 kg
Fuel tank 25 l
Cleaning-agent tank 20 + 17 l
