English 15
Symbols on the device
Environmental protection
The packing materials can be recycled. Please
dispose of packaging in accordance with the en-
vironmental regulations.
Electrical and electronic devices contain valua-
ble, recyclable materials and often components
such as batteries, rechargeable batteries or oil,
which - if handled or disposed of incorrectly - can
pose a potential danger to human health and the envi-
ronment. However, these components are required for
the correct operation of the device. Devices marked by
this symbol are not allowed to be disposed of together
with the household rubbish.
Cleaning work producing in oily waste water, e.g.
washing engines, washing undercarriages etc.,
may only be performed at washing stations with an oil
separator.
Working with detergents may only be performed on
watertight surfaces with connection to the waste
water sewage system. Do not allow detergent to enter
waterways or the soil.
Extraction of water from public waterways is not
permitted in some countries.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Intended use
Use the high-pressure cleaner in private households
only.
The high-pressure cleaner is intended for cleaning ma-
chines, vehicles, buildings, tools, façades, terraces,
garden machines etc. using a high-pressure water jet.
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.
Description of the device
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page
Illustration A
Illustration B
1 Stand with carrying handle
2 Water connection with integrated sieve
3 Transport wheel
4 Visor
5 Hose guide
6 Trigger "0/OFF" / "I/ON"
7 Storage for spray lance
8 High-pressure hose
9 *Plug 'n' Clean detergent bottle
10 Storage / parking position for high-pressure gun
11 3-in-1 multi-jet spray lance with 3 spray types (see
also chapter Smart Control System)
12 Smart Control high-pressure gun
13 LCD display (see also chapter LCD display)
14 Battery compartment lock
15 Battery compartment
16 “+/-” buttons for pressure control
17 High-pressure gun lock
18 Button for separating the high-pressure hose from
the high-pressure gun
19 High-pressure gun lever
20 Transport handle, telescoping
21 Carrying handle
22 Hose holder
23 High pressure hose reel
24 Crank handle for hose reel
25 Type plate
26 Accessory compartment
27 Hook for net attachment
28 Accessory compartment net
29 Mains connection with mains plug
30 Supplied screws and dowels
31 Water connection coupling
32 * Garden hose (fabric reinforced, diameter at least
1/2 inch (13 mm), length at least 7.5 m, with com-
mercially available quick coupling)
33 * KÄRCHER suction hose for water supply from
open containers (order no. 2.643-100.0)
* additionally required
LCD display
Illustration C
1 Area of application (1-SOFT / 2-MEDIUM / 3-HARD
with 2 pressure levels each)
2 BOOST function indicator
3 Spray type recommendation (flat stream/detergent/
dirt blaster)
4 Display Bluetooth
®
connection
Do not aim the high-pressure jet may at per-
sons, animals, live electrical equipment or
the device itself.
Protect the device against frost.
The device may not be connected to the
public drinking water network.
