Kärcher Puzzi 8/1 - Technical Data; Electrical Connection and Performance; Dimensions, Weights, and Ambient Conditions; Determined Values and Mains Cable

English 13
Technical data
Subject to technical modifications.
Puzzi 8/1
Electrical connection
Mains voltage V 120
Phase ~ 1
Power frequency Hz 60
Degree of protection IPX4
Protection class II
Rated current A 9
Spray pump power W 40
Device performance data
Fresh water filling quantity gal (l) 2.1 (8)
Wastewater filling quantity gal (l) 1.8 (7)
Air quantity (max.) CFM 
(l/s)
150 (71)
Vacuum (max.) mm
(kPa)
2590 (25.4)
Spray pressure psi
(MPa)
14.5 (0.1)
Spray pressure (max.) psi
(MPa)
43.5 (0.3)
Spray volume gal/min
(l/min)
0.26 (1)
Cleaning solution temperature (max.) °F (°C) 122 (+50)
Dimensions and weights
Typical operating weight lbs (kg) 19.0 (8.6)
Length x width x height in (mm) 20.5 x 13.0 x 16.5 (525 x 335 x
425)
Ambient conditions
Ambient temperature (max.) °F (°C) 104 (+40)
Determined values in acc. with EN 60335-2-68
Sound pressure level L
pA
dB(A) 72
Uncertainty K
pA
dB(A) 1
Hand-arm vibration value m/s
2
<2.5
Uncertainty K m/s
2
0.2
Mains cable
Power cord type SJTW 2/16 AWG
Part number (CUL) 6.648-222.0
Cable length ft (m) 33 (10)
