Kärcher SC 1.020 Quick Reference

– 12
Often, failures have simple causes and you
can do the troubleshooting yourself using
the following overview. If you are in doubt
or if the failure is not listed here please con-
tact the authorized customer service.
 Danger
Always disconnect the mains plug and al-
low the steam cleaner to cool down before
performing any maintenance work.
Repair works may only be performed by the
authorized customer service.
 Descale the steam boiler.
 Turn off the appliance.
 Refill water
Steam switch is secured with the lock /
child-proof lock.
 Move the selector switch for the steam
volume to the front.
 Press the steam gun until less water is
emitted.
 Descale the steam boiler.
Subject to technical modifications!
Troubleshooting
Long heating-up time
Steam boiler is decalcified
No steam
No water in the steam boiler.
Steam lever cannot be pressed
anymore
High water output
Steam chamber too full
Steam boiler is decalcified
Technical specifications
Power connection
Voltage 120-127 V
1~60 Hz
Protective class I
Protection class IPX4
Performance data
Heating output 1500 W
Operating pressure
max.
0,32 MPa
Heating time 6 Minutes
Steam volume g/min
Continuous steaming 50 g/min
Steam push max. 110 g/min
Dimensions
Boiler capacity 1,0 l
Weight (without acces-
sories)
3,1 kg
Width 250 mm
Length 382 mm
Height 256 mm
20 EN

Kärcher SC 1.020 Specifications

General

Type	Cylinder steam cleaner
Capacity	1 L
Cord length	4 m
Product color	Black, Yellow
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Ready time	8 min
Steam pressure	3.2 bar
Hard floor brush	Yes

Weight and Dimensions

Depth	380 mm
Width	254 mm
Height	260 mm
Weight	3000 g
