Boiler thermostat
The boiler thermostat switches off the heating in the
event of a fault; for example, if there is no water in the
steam boiler and the temperature in the steam boiler ris-
es.
As soon as you refill the water, the device is ready for
use again.
Maintenance lock
The maintenance lock seals the steam boiler from the
steam pressure present. The maintenance cap is also a
pressure relief valve. If the pressure regulator is defec-
tive and the steam pressure in the steam boiler rises,
the pressure relief valve opens and steam is escapes
through the lock.
Prior to restarting the device, contact the responsible
KÄRCHER Customer Service.
Description of the device
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page.
Illustration A
1 Device socket with cover
2 Water reservoir
3 Carrying handle for the water reservoir
4 Selector switch
5 Control panel
6 Display - OFF position
7 Display - water shortage (red)
8 Display - heating (green)
9 Steam stage 1
10 Steam stage 2
11 Steam stage 3
12 Steam stage 4
13 VapoHydro function steam stage
14 Display - iron detection
15 Display - steam gun detection
16 Cap for accessory compartment
17 Maintenance lock
18 Carrying handle
19 Holder for accessories
20 Accessory storage compartment
21 Mains connection cable storage compartment
22 Park bracket for floor nozzle
23 Mains connection cable with mains plug
24 Non-driven wheels (2 x)
25 Steering roller
26 Steam gun
27 Steam lever
28 Unlocking button
29 Child lock
30 Steam hose
31 Steam connector
32 Spotlight nozzle
33 Round brush (small, black)
34 ** Round brush (small, yellow)
35 Power nozzle
36 Round brush (large)
37 Manual nozzle
38 Microfibre cover for manual nozzle
39 Extension tubes (2 x)
40 Unlocking button
41 Floor nozzle
42 Hook and loop fastener
43 Microfibre floor cloth (2 x)
44 Carpet glider
45 Descaler
46 ** Steam pressure iron
47 Indicator light (orange) - heating
48 Steam switch (bottom)
49 Steam connector
** optional
Installation
Installing accessories
1. Open the cover on the device socket.
Illustration B
2. Connect the steam connector to the device socket
so that the steam connector audibly engages.
Illustration B
3. Push the open end of the accessory onto the steam
gun so that the unlocking button on the steam gun
engages.
Illustration H
4. Push the open end of the accessory onto the spot-
light nozzle.
Illustration I
5. Connect the extension tubes with the steam gun.
a Push the 1st Push the first extension tube onto
the steam gun so that the unlocking button on the
steam gun engages.
The connection pipe is connected.
b Push the 2nd extension tube onto the
1st extension tube.
The connection pipes are connected.
Illustration J
6. Push the accessory and / or the floor nozzle onto the
free end of the extension tube.
Illustration K
The accessory is connected.

Kärcher SC 5 EasyFix Premium Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 Hz
Steam pressure	4.2 bar
Adjustable steam	Yes
Type	Cylinder steam cleaner
Capacity	1.5 L
Cord length	6 m
Hose length	2.3 m
Product color	Black, White
Waste tank capacity	0.5 L
Steam-ready light	-

Weight and Dimensions

Depth	439 mm
Width	301 mm
Height	305 mm
Weight	6000 g
Package weight	10800 g
