Kärcher SP 2 Flat - Technical Specifications; Specification Data Table; Performance Curves

– 6
Subject to technical modifications!
Specifications
SP 2 Flat MX SP 3 Dirt BR/MX SP 3 Dirt BR
Voltage V
120 - 127 V 120 - 127 V 220 V
C
urrent type Hz 606060
Output P
nom
W 320 350 400
Max. flow rate l/h 6500 7000 8000
Max. pressure bar 0.65 0.6 0.6
Max. flow height m 5 6 6
Max. immersion depth m 6.5 7 7
Max. grain size of the dirt particles
that can be transported
mm 5 20 20
Minimum fluid height (manual mode) mm 7 60 60
Residual fluid height mm 1 25 25
Weight (without accessories) kg 3.8 4.2 4.2
The possible delivery rate is even larger:
– the lower the delivery height
– the larger the diameter of the hose used
– the shorter the hose used
– the lower the pressure loss caused by the connected accessories
23EN
