Assembly Instructions – 4089P

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 1

*PLEASE READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO ASSEMBLING, INSTALLING, AND

USING THIS PRODUCT.*

Warning

Always check for wires, fuel tanks and lines, brake lines and other important vehicle

functionality items prior to drilling and installing all products.

Tools Needed

1/2” Socket and Wrench

9/16” Socket and Wrench

Tape Measure

Table of Contents

Before You Begin ..................................................................................................................................................... 1

Parts List ................................................................................................................................................................... 2

Hardware 18-4089P ................................................................................................................................................ 2

Step 1 – Find Mount Locations on Roof of Van ..................................................................................................... 3

Step 2 – Install Feet ................................................................................................................................................. 4

Step 3 – Measure distance between feet .............................................................................................................. 5

Step 4 – Mount Rack ............................................................................................................................................... 5

Before You Begin

 Read all instructions.

 Use these instructions along with the assembly instructions found with the rack to complete installation.

 The 3/8” hardware will be used when installing the rack to the feet.
