Karma Flexx HD - Anti-Tippers (Optional)

20
4.13.7 Place the eccentric hexagonal pads in the appropriate direction, and lock the
screws and nuts of the front caster adapter.
Figure 4.46
Figure 4.47
4.13.8 Different caster positions are available based upon the selection of
seat height, castors and rear wheels. Please refer to Section 5.3.2 &
5.3.3 Seat Height Adjustment for Rear Wheels.
4.13.9 Please refer to the Flexx series Maintenance Manual about how to
adjust the caster angle.
4.13.10 Please take advice from your authorized dealer, technician or
qualified therapist, if you want to replace a fork or castors or rear
wheels.
4.14 Anti-Tippers (Optional)
The main purpose of anti-tippers is to prevent the user from tipping over
backward.
4.14.1 When you install the anti-tippers, if the anti-tippers are adjustable,
please make sure the distance between the end of each anti-tipper
and the rear wheel is at least 5cm; the distance to the floor does not
exceed 5cm.
4.14.2 To avoid the attendant from stumbling when pushing it forwards/
backwards, be sure to put the anti-tippers away by treading them in
clockwise/ counterclockwise directions. (See Figure 4.48 and Figure
4.49)
