5.3.4 Backrest Angle Adjustment.
● Loosen bolt A and nut B. Remove the arc washers C.
● Adjust the backrest tube to the desired position and angle. (from -4〫to
16〫)
● Insert bolt A into the new position, and align arc washers C with the
angle number specified in the above figure. Tighten bolt A and nut B
with washer D.
● Repeat the above procedures on the other side of the chair.
● Anti-tippers MUST be equipped, when the backrest angle is set as greater
than or equal to four degrees.
6. ACCESSORIES
Optional accessories are as below, please contact your dealer for the
purchase of these items.
6.1 Pneumatic rear wheels.
6.2 Aluminum handrim.
6.3 6", 7”and 8" caster.
6.4 Attendant brake.
6.5 Swing away anti-tipper.
6.6 IV pole holder.
6.7 Oxygen tank holder.
6.8 Hub brake.
6.9 Tie-down bracket
