5. OPERATION
5.1 Controller Cable Tie Location
5.1.1 The controller for the Blazer series is packaged in the carton; after
opening the carton, the controller needs to be equipped to the correct
position by fastening two screws.
5.1.2 In the case that the controller cable ties becomes loose, please refer to
the below figure for the locations to fasten the cable ties, and follow the
instructions:
5.1.2.1 At Section A (see the figure below), loosen the cable and leave some
of the cable hanging because it facilitates the armrest height
adjustment.
5.1.2.2 At Section B (see the figure below), cross the cable tie around the
screw. It provides better fixation and keeps the cable tie from sliding
out of place.
5.1.2.3 The other areas circled also indicates the cable tie locations.
● The controller cable must be fixed as instructed above, otherwise the cable could
be damaged and cause malfunction of the wheelchair.
