7.7 Instructions for Lubrication
7.7.1 Left & right caster bracket. (Figure 7-1)
7.7.2 Left & right joint of backrest. (Figure 7-2)
7.7.3 Left & right connecting tubes. (Figure 7-3)
7.7.4 Left & right trunnions. (Figure 7-4)
● When lubricating, apply only 1-2 drops of oil (not grease), as extra oil will
drip on the rug and cause pollution as a result of over-lubrication.
● Depending on how often you use the chair, normally 1-2 times of
lubrication per month is fine. Proper lubrication can extend the life span of
a part in addition to prevent noise from accruing. Check if the bolts are
fastened while lubrication.
