Karma KP-31 User Manual

21
the tires pressure specified on the tire walls to maintain the tires at
the correct pressure. Do not let anyone touch the wheels when the
wheelchair is in motion to avoid pinch injury.
5.3 How to Adjust Your Wheelchair
5.3.1 Swing-Away and Detach Footrest
To swing away and detach the footrests, pull the swing-away lever
(See Figure 5-7), then you can swing away and/or detach the
footrests. (Figure 5-8) It can make transferring in and out of the
wheelchair easier. Blazer series can also be mounted with other types
of KARMA footrests.
Figure 5-7
Figure 5-8
Figure 5-9
Figure 5-10
5.3.2 Footrest Adjustment in Longitudinal (Fore/Aft) Position
Please use the #5 Allen Key Wrench included in your KARMA Tool Kit
(Figure 5-9) to make this adjustment. Remove the screws under the seat
(Figure 5-10) then adjust the footrest to accommodate the user's leg
position and flexibility (Figure 5-11). Re-tighten the screws.
Figure 5-11
Figure 5-12
5.3.3 Footplates Adjustment
The footplate length should be adjusted according to the user's calf
length. Go to your service provider for adjustment or follow below
instructions:
5.3.3.1 Use the #5 Allen Key Wrench from KARMA Tool Kit to loosen the bolt
