27
4.2.5 Conveyor Stop
The conveyor stop is used to position the filled envelopes neatly onto the conveyor. Adjust
the sliding plate to the size of envelope being used with the thumbscrew on top.
4.2.6 Feed Gates (Envelope Hopper)
Set as in section 3.1
4.2.7 Inserting Shoes
The inserting shoes act as a guide for the documents as they are pushed into the envelope. To
remove them, turn the thumbscrew anticlockwise until the shoe can be withdrawn from its
location slot. To replace, insert the shoe into the location slot, aligning the holes, and tighten
the thumbscrew.
Machine Size Shoe Size Supplied Max. Document Thickness
6 station machine 6mm and 9mm 5mm and 8mm
3 station machine 6mm 5mm
3mm shoes for thin documents are also available upon request.
Sliding
Plate
Thumbscrew
Inserting Shoes
Thumbscrew
