5. Specifications
HS565 Mailmaster
Maximum cycle speed 7200 insertions per hour
Max packing thickness Up to 8mm
Envelope type Wallet with or without window
Envelope Feeder
Envelope dimensions Minimum Maximum
Length 220mm 242mm
Depth 108mm 165mm
Flap 32mm 58mm
Throat 12mm 25mm
Recommended envelope weight 90gsm to 120gsm
Document Feeder
Minimum Maximum
Insert dimensions 160mm × 80mm 216mm × 155mm
Insert thickness 70gsm sheet 1.5mm
Book Feeder
Minimum Maximum
Insert dimensions 160mm × 80mm 216mm × 155mm
Insert thickness 70gsm sheet 5mm
It is possible that inserts not meeting these dimensions can be catered for upon request.
Electrical supply 220-240V 50Hz 1.1A (110V 60Hz 3.2A)
