6.0 Fold examples
Top left hand address Z fold
Plate 1: Set to 200mm.
Plate 2: Set to 105mm.
Paper Feed: Top edge leading, address face up.
Top left hand address wrap fold
Plate 1: Set to 95mm.
Plate 2: Set to 105mm.
Paper Feed: Bottom edge leading, address face down.
Top left hand address V fold
Plate 1: Set to 150mm.
Plate 2: Set to deflect.
Paper Feed: Bottom edge leading, address face down.
