Instructions for use
KEY Laser III 1243
Always be on the safe side.
2
Table of Contents
Default Chapter
3
Table of Contents
3
Contents
3
1 User Notes
6
Purpose - Proper Use
6
Training Opportunity
6
Effects
6
Indications and Contraindikations
6
Important Instructions
9
Registration
9
Packages
10
Weight and Markings
10
The German Packaging Ordinance, 28 August 1998
10
Service
12
2 Safety
13
Safety Instructions
13
Description of Danger Levels
13
Hazard Levels
13
Warning Symbol
13
Structure
13
Laser Safety
14
Safety Instructions
14
Safe Use
16
General Safety Instructions
16
Disposal of Waste and Residue from the Device and Accessories at the End of Use
17
Personal Eye Protection
18
Safety of the Construction
18
Electromagnetic Compatibility
18
Safe Laser Range
20
Warning Lamps
20
Warning Signs
21
Electromagnetic Transmissions
22
Guidelines and Manufacturer's Statement - Electromagnetic Transmission
22
Guidelines and Manufacturer's Statement - Electromagnetic Immunity
23
Guidelines and Manufacturer's Statement - Electromagnetic Immunity
24
3 Description of Instrument
27
KEY Laser 1243 (Material No. 1.000.5342)
27
Multifunction Foot Control
28
Back of the Laser Unit
29
Touch Screen
31
Model and Rating Plate
32
Where to Affix the Laser Warning Signs and Laser Note
33
Technical Data and Requirements
35
4 Operation
38
Emergency Laser Stop
38
Filling Spray Water
39
Laser Tube/Handpieces
40
Laser Tubing
40
Coupling Handpieces
40
Disconnection
42
Switch on
44
Energy-Saving Mode
45
Touchscreen Operation
46
Ready Mode
47
Triggering Laser Pulses
47
Interruption of Ready Mode
48
Ending the Ready Mode
48
Setting Pulse Energy and Pulse Frequency
49
Selecting Pulse Energy
49
Selecting Pulse Frequency
49
User Test with Hand Piece 2060
51
Modes
52
Changing the Mode
52
Standard Therapy Mode
53
Detect Mode
53
Feedback Mode
54
Threshold Setting
55
Spray Settings
57
Medium Preselection
57
Foot Control
58
Spray Test
58
System Menu
59
Programs
61
Program Selection
61
Program Selection Menu
61
System Menu
62
Deleting a Program
62
Changing a Program Setting
63
Reset New Settings
63
Pilot Jet Setting
63
Handpiece Selection
65
New Program
66
Saving a New Program
66
Deleting a Program
67
Detector Calibration
68
Check or Change Reference Value
68
Starting the Calibration
69
Setting Zero Value
69
Determining the Reference Value
70
Completing the Detector Calibration
71
Spray Regulation
72
Switch off
73
5 Care
74
Machine Cleaning and Care
74
Machine Disinfection
75
Care, Sterilisability and Disinfectability of Handpieces
76
Cooling Circulation
77
6 Safety Checks
78
Scope of the Tests
78
Manual 'Energy' Safety Check
79
Handpieces
80
Earthed Conductor Test According to DIN VDE 0751-1
81
Spare Unit Leakage Current Test According to DIN VDE 0751-1
82
Further Tests
83
Safety Check Report
84
7 Accessories
85
Handpieces
85
Warning Signs
87
Laser Protective Eye Wear
88
References
89
8 Faults
90
Fault Messages
90
Warning
91
Faults
92
Troubleshooting
93
9 Assembly Notes
95
Characteristics of the Floor
95
Media
96
Spray Water
96
Spray Air
96
Electrical Connection
97
Local
97
Version at Unit
97
100-127V Version at Unit
97
Transport and Storage
98
Procedure to Follow in the Event of Damage Caused in Transit
99
Installation Plan
100
Mounting of Door Switches
101
