© 1998 KB Electronics, Inc.
INSTALLATION AND OPERATING INSTRUCTIONS
MODEL KBPC-240D
KB Part No. 9338 (Black Case) • Part No. 9342 (White Case)
NEMA 4X, IP-65
SCR Speed and Torque Control Designed
For DC Motors Rated
1/50 – 1 HP @ 90VDC, 1/25 – 2 HP @ 180VDC
T
See Safety Warning on Page 2
The information contained in this manual is intended to be accurate. However, the manufacturer
retains the right to make changes in design which may not be included herein.
