FIGURE 1 – CONTROL LAYOUT & MECHANICAL SPECIFICATIONS (INCHES / [mm])

(Illustrates Factory Setting of Jumpers and Approximate Trimpot Settings)

MAX

VOLT CUR

MIN

2345678910

(4) mounting holes for #6 screws

2.244

[57.0]

0.276

[7.00]

0.276

[7.00]

4.291

[109.00]

4.843

[123.00]

2.795

[71.0]
