Technical data
3 Technical data
3.1 Power supply
Power supply 85 - 265V AC/DC ; <10VA
3.2 Electrical connection
Connection elements Plug terminals
Permissible cross section
of the connection lines
Power supply 2.5 mm
2
,
bus connection 1.5 mm
2
Input
control voltage
Fusing max. 6 A
LAN connection 8P8C modular connector (RJ 45)
BUS connection Connection
material
For proper operation,
use shielded twisted-pair cables only,
e.g. I-Y(St)Y 2x2x0.8
Modbus serial
connectors
for connection
via RS-485
Device:
Terminal 90 (
)
Terminal 91 (A)
Terminal 92 (B)
3.3 Mechanical data
Top hat rail device Housing
dimensions
90 x 36 x 61 mm (H x W x D)
Mounting type Wall mounting on DIN rail 7.5 mm
deep, in accordance with DIN EN
50022, suitable for distribution
board mounting
Weight Approx. 120 g
