KEB COMBILINE 24Z2F04-1003 User Manual

18
DEVICE DATA
3.2 Device data
3.2.1 Mechanical data of the motor chokes
Material
number
Connection
Typ.
conductor
cross-
section in
mm² / AWG
Tightening torque
in Nm / lb inch With
temperature
switch
Type U, V, W PE U, V, W PE
07Z2F04-1003
Terminal
Push-Lock 6 / 10 — —
—
09Z2F04-1003 —
10Z2F04-1003 —
12Z2F04-1003 —
13Z2F04-1003
RK 6-10/35 M6 10 / 8 2 / 17.7 4.5 / 39.8
—
14Z2F04-1003 —
15Z2F04-1003 —
16Z2F04-1003 —
17Z2F04-1003
RK 16/35
M8
16 / 6 4 / 35.4
10 / 88.5
—
18Z2F04-1003 —
19Z2F04-1003 RK 35/35 35 / 2 5 / 44.3 —
20Z2F04-1003
Bolt
M10
25 / 4
20 / 177
—
21Z2F04-1003
35 / 2
—
22Z2F04-1003 —
23Z2F04-1003
M10
50 / 1
20 / 177
—
24Z2F04-1003
70 / 2/0
—
25Z2F04-1003
✓
26Z2F04-1003
M12
95 / 3/0
40 / 354
✓
27Z2F04-1003
✓
28Z2F04-1003 120 / 4/0
✓
29Z2F04-1003 150 / 250
✓
30Z2F04-1003 240 / 450
✓
All data are rated values
Table 5: Mechanical data of the motor chokes
NOTICE
Overheating of the motor choke !
► Motor chokes from size 25 must be ventilated !
Further information
=> „Ventilation of the motor chokes from size 25“.
