INSTALLATION AND CONNECTION

4.5.5 Connection of the capacitor module with three power capacitors

Legend

PE Protective earth connection via connection point on the retaining plate

3 x FlatAL 80x2mm;

Drilling:

⌀ = 13mm

Capacitor connection for M12 screw

Figure 20: Connection of the capacitor module with three power capacitors

The 3 phases can be contacted at the 3 connection points.
