19
DEVICE DATA
3.2.2 Electrical data of the motor chokes
Material
number
Current
in A
Inductance
in mH
1)
Resistance
in mΩ
1)
Frequency
in Hz
Typically
power loss
Frequency
range
in Hz
at 600Hz
in W
at 800Hz
in W
at 1600Hz
in W
07Z2F04-1003 2.6 3.5 407 800
—
18 26.5
0...1600
09Z2F04-1003 4.1 2.2 198 800 32 44
10Z2F04-1003 5.8 1.5 172 800 48 74
12Z2F04-1003 9.5 0.967 104 800 99 136
13Z2F04-1003 12 0.766 52 800 35 46
14Z2F04-1003 16.5 0.557 31 800 44 61
15Z2F04-1003 24 0.383 22 800 66 92
16Z2F04-1003 33 0.278 16 800 102 135
17Z2F04-1003 42 0.219 9.52 800 115 148
18Z2F04-1003 50 0.184 6 800 92 109
19Z2F04-1003 60 0.153 6 800 124 152
20Z2F04-1003 75 0.123 6.1 800 152 180
21Z2F04-1003 90 0.102 3.6 800 147 177
22Z2F04-1003 115 0.08 3.7 800 224 264
23Z2F04-1003 150 0,082 2.4 600 264
—
340
24Z2F04-1003 180 0.068 2.4 600 390 530
25Z2F04-1003 210 0,058 1.5 600 430 572
26Z2F04-1003 250 0.049 1 600 492 732
27Z2F04-1003 300 0.041 1 600 515 852
28Z2F04-1003 370 0.033 0.58 600 515 935
29Z2F04-1003 460 0.027 0.48 600 777 1079
30Z2F04-1003 570 0.021 0.39 600 963 1122
Table 6: Electrical data of the motor chokes
1)
Limit deviation ±10%.
• Rated voltage corresponds to U
N = 400 / 480V.
• All data are rated values except minimum and maximum values.
• The output frequency is to be limited in such a way that it does not exceed 1/10 of the switching
frequency.
