DIMENSIONS AND WEIGHTS

3.3 Dimensions and weights

3.3.1 Motor chokes size 07 to 12

Mounting direction

Size B H H1 T L1 L2 L3 d1 d2 Weight

07Z2F04-1003

130 371 400 85 100 — 350 5.5 5.5

3.5

09Z2F04-1003 3.9

10Z2F04-1003 4.1

12Z2F04-1003 4.7

Figure 1: Dimensions and weights motor chokes size 07 to 12

All dimensions in mm; all weights in kg.
