GB-25
Parameter Lists
‘1 LF.06 = 1 high-resolution on
Gr. No. Name Address P E R Resol. Lower Limit Upper Limit Default Value Unit
LF 64 DC-voltage circuit control 3540 1 0 800 0 V
LF 65 E.dOH deceleration time 3541 1 0 3600 300 s
LF 66 Heat sink temperature level 3542 1 20 50 40 °C
LF 67 Pretorque gain 3543 0,01 0,50 1,50 1,00 ---
LF 68 Pretorque offset 3544 0,1 -25,0 25,0 0,0 %
LF 69 Pretorque reversal of direction 3545 1 0:off 1:on 0:off ---
LF 70 Brake release time 3546 0,001 0,000 3,000 0,300 s
LF 71 Crawl path optimization rated speed VN 3547 0,1 0,0 200,0 0,0 cm
LF 72 Crawl path optimization speed V1 3548 0,1 0,0 200,0 0,0 cm
LF 73 Crawl path optimization speed V2 3549 0,1 0,0 200,0 0,0 cm
LF 74 Crawl path optimization crawl speed VE 354A 1 0 300 0 mm
LF 75 Ogive function 354B 1 0:off 1:on 0:off ---
LF 76 Ogive status 354C R --- --- --- --- ---
LF 77 Braking distance 354D 0,001 0,000 5,000 0,000 m
LF 79 Brake engage time 354F 0,001 0,000 3,000 LF.70 s
LF 80 Software version 3550 R --- --- --- --- ---
LF 81 Software date 3551 R --- --- --- --- ---
LF 82 X2 input state 3552 R --- --- --- --- ---
LF 83 X2 output state 3553 R --- --- --- --- ---
LF 84 X3 input state 3554 R --- --- --- --- ---
LF 85 X3 output state 3555 R --- --- --- --- ---
LF 86 Actual set value 3556 R --- --- --- --- ---
LF 87 Actual inverter utilization 3557 R --- --- --- --- %
LF 88 Actual set speed 3558 R 0,5 --- --- --- rpm
0,1 '1
LF 89 Actual speed 3559 R 0,5 --- --- --- rpm
0,1 '1
LF 90 Actual car speed 355A R --- --- --- --- m/s
LF 92 Crawl distance 355B R --- --- --- --- cm
LF 93 Total path 355C R --- --- --- --- cm
LF 98 Error status in starting procedure 3562 R --- --- --- --- ---
LF 99 Inverter state 3563 R --- --- --- --- ---
