GB-28
5.5 ru-Parameter
Parameter Lists
‘1 High-resolution at LF.06 = 1
5.6 In-Parameter
Gr. No. Name Address P E R Resol. Lower Limit Upper Limit Default Value Unit
ru 00 Display inverter status 2000 R Table -
ru 01 Display actual speed 2001 R 0,5 --- --- --- rpm
0,1 '1
ru 02 Actual torque display 2002 R 0,1 --- --- --- Nm
1 '1
ru 04 Set speed display 2004 R 0,5 --- --- --- rpm
ru 05 Display setpoint torque 2005 R 0,1 --- --- --- Nm
1 '1
ru 08 Peak inverter utilization 2008 0,1 --- --- --- %
ru 09 Apparent current 2009 R 0,1 --- --- --- A
ru 10 Active current 200A R 0,1 --- --- --- A
ru 11 Actual DC voltage 200B R 1 --- --- --- V
ru 12 Peak DC voltage 200C R 1 --- --- --- V
ru 14 X2 Input terminal status 200E R Table --- --- ---
ru 15 X2 Output terminal status 200F R Table --- --- ---
ru 18 Actual parameter set 2012 R Table --- --- ---
ru 20 Speed reference display 2014 R 0,5 --- --- --- rpm
0,1 '1
ru 23 REF 2 display 2016 R 0,1 --- --- --- %
ru 24 OL counter display 2018 R 1 --- --- --- -
ru 25 Peak apparent current 2019 R 0,1 --- --- --- A
ru 29 Heat sink temperature 201D R 1 --- --- --- °C
ru 31 Power on counter 201F R 1 --- --- --- h
ru 32 Modulation on counter 2020 R 1 --- --- --- h
ru 50 Display of feeback power 2032 R 1 --- --- --- kWh
Gr. No. Name Address P E R Resol. Lower Limit Upper Limit Default Value Unit
In 00 Inverter type display 2C00 Table --- --- --- ---
In 01 Rated inverter current 2C01 0,1 --- --- --- A
In 06 Configfile number 2C06 R 1 --- --- ---
In 07 Serial number high 2C07 1 0 65535 0 ---
In 08 Serial number low 2C08 1 0 65535 0 ---
In 09 Serial number order no. high 2C09 1 0 65535 0 ---
In 10 Serial number order no. low 2C0A 1 0 65535 0 ---
In 11 Customer number HIGH 2C0B 1 0 65535 0 ---
In 12 Customer number LOW 2C0C 1 0 65535 0 ---
In 40 Last error 2C28 1 0 63 0 ---
In 41 Error counter OC 2C29 1 0 255 0 ---
In 42 Error counter OL 2C2A 1 0 255 0 ---
In 43 Error counter OP 2C2B 1 0 255 0 ---
In 44 Error counter OH 2C2C 1 0 255 0 ---
In 45 Error counter WD 2C2D 1 0 255 0 ---
In 54 Software ID version DSP 2C36 R --- --- --- ---
In 55 Software date DSP 2C37 R --- --- --- ---
In 60 Display Last error (t-1) 2C3C R 1 --- --- --- ---
In 61 Display Last error (t-2) 2C3D R 1 --- --- --- ---
In 62 Display Last error (t-3) 2C3E R 1 --- --- --- ---
In 63 Display Last error (t-4) 2C3F R 1 --- --- --- ---
In 65 Braking resistance 2C41 0,1 0,1 100,0 12,0 Ohm
