GB-9
12345
67
8
9
10
1112131415
The incremental encoder of the motor is connected to the 15-pole sub-
D-socket.
2.3 Connection X4
The connector may only
be connected /
disconnected when the
inverter and voltage
supply are shut off.
Connection
2.3.1Connection
Incremental Encoder
PIN-No. Signal PIN-No. Signal
1- 9B +
2-10-
3 A - 11 + 15 V
4B -12+ 5 V
5 - 13 GND
6-14N -
7-15N+
8 A + Housing Shield
Encoder 1
12345
67
8
9
10
1112131415
PIN-No. Signal PIN-No. Signal
1C - 9B +
2D - 10
3A -11
4B -12+ 5 V
5 13 GND
6C +14R -
7D +15R +
8 A + Housing Shield
2.3.2Connection
SIN/COS Encoder
The connector may only
be connected /
disconnected when the
inverter and voltage
supply are shut off.
12345
67
8
9
10
1112131415
PIN-No. Signal PIN-No. Signal
1 9 COS
2 10 SIN_REF
3 SIN_LO 11
4 COS_LO 12
5 SIN_REF_LO 13
614
715
8 SIN Housing Shield
The connector may only be connected / disconnected when
the inverter and voltage supply are shut off.
2.3.3Connection Resolver
