GB - 11
Diag Error Counter 0183h (OS.03) not available
Meaning: Counts errors on the diagnosis interface.
Data Length: 2 Byte
Coding: 1
Remarks: Only for information
DiagRsp.DelayTime 0184h (OS.04) not available
Meaning: Response delay time on the diagnosis interface.
Data Length: 1 Byte
Coding: 1 ms
Remarks: A changed value will immediately be active and non-volatile saved.
Diag Baudrate 0185h (OS.05) not available
Meaning: Configures the transmission speed on the diagnosis interface.
Data Length: 1 Byte
Coding: 0: 1200 Bit/s
1: 2400 Bit/s
2: 4800 Bit/s
3: 9600 Bit/s
4: 19200 Bit/s
5: 38400 Bit/s
Remarks: This Parameter can only read by the diagnosis interface.
HSP5_Max_InvBusy_Retries 0186h (OS.06) not available
Meaning: Configures how often the ModBus operator repeats a request to the frequency inverter
control if this answers with error code ‚inverter busy‘.
Data Length: 1 Byte
Coding: 1
Remarks: A changed value will immediately be active and non-volatile saved.
HSP5 Tout Cnt 0187h (OS.07) not available
Meaning: Counts the occurrences of timeout on the interface between ModBus operator and
frequency inverter control.
Data Length: 2 Byte
Coding: 1
Remarks: Only for information
Operator Parameters
Software date 0182h (OS.02) not available
Meaning: Configures the software date.
Data Length: 2 Byte
Coding: The lowest decimal digit configures the year 2000.
The next two decimal digits configure the month.
The next two decimal digits configure the day.
Remarks: The representation is as follows: ddmm, year-2000
