GB - 12
ModBus COMBIVIS Name Data length
Address Para. Address in Byte
——— 0180h Operator Type 2
——— 0182h Software date 2
——— 0183h Diag Error Counter 2
——— 0184h DiagRsp.DelayTime 1
——— 0185h Diag Baudrate 1
——— 0186h HSP5_Max_InvBusy_Retries 1
——— 0187h HSP5 Tout Cnt 2
5F00h 0280h MDB_ProtCfg 1
5F01h 0281h MDB_SlaveAddr_OP 1
5F02h 0282h MDB_MapStartAddr_Rd 2
5F03h 0283h MDB_MapStartAddr_Wr 2
5F04h 0284h MDB_MapNr_Rd 1
5F05h 0285h MDB_MapNr_Wr 1
5F06h 0286h Watchdog_Inhibit 1
5F07h 0287h Watchdog_Activation 1
5F31h 0288h MDB_Command 2
5F32h 0289h + 028Ah MDB_Mapping_Rd_0 4
: : : :
5F95h 0289h + 028Ah MDB_Mapping_Rd_99 4
5F96h 028Bh + 028Ch MDB_Mapping_Wr_0 4
: : : :
5FF9h 028Bh + 028Ch MDB_Mapping_Wr_99 4
4 Annex
4.1 Table of Operator
Parameters
Error Code Meaning
1 Illegal function
2 Illegal data address
3 Illegal data value
4 Slave device failure
5 Function accepted but not yet finished
6 Slave device busy
64 Internal buffer overflow
65 Timeout at transfer to frequency inverter control
66 Parameter is write protected
67 Invalid password
4.2 Error Codes of
Exception Response
[1]: Modicon ModBus Protocol Reference Guide, PI-MBUS-300 Rev.J v. 06/1996
[2]: ModBus Application Protocol Specification V1.1 v. 12/06/02
[3]: ModBus over Serial Line Specification & Implementation Guide V1.0 v. 12/02/02
5. References
