By this function a number of 32 bit registers/parameters can be read.
Function 100 – Request:
FUNC
100(dez)
Start-Addr
SL-Addr
HiByte
LoByte
Number
HiByte
LoByte
CRC
LoByte
HiByte
with Number: Number of registers/parameters to read
with Start-Addr: First read register address
Function 100 – Response:
FUNC
100(dez)
SL-Addr
MSByte
LSByte
Byte_Cnt
1. Parameter-Wert
MSByte LSByte
n. Parameter-Wert
CRC
LoByte
HiByte
2.4 ModBus Functions
Defined By KEB
2.4.1 Function 100:
Read Registers32
By this function a number of 32 bit registers can be written.
Function 101 – Request:
FUNC
101(dez)
SL-Addr
HiByte
Byte_Cnt
Start-Addr
MSByte LSByte
1. Parameter-Wert
CRC
LoByte
HiByte
LoByte
HiByte
Number
LoByte
MSByte LSByte
n. Parameter-Wert
with Number: Number of registers/parameters to read
with Start-Addr: First read register address
Function 101 – Response:
FUNC
101(dez)
Start-Addr
SL-Addr
HiByte
LoByte
Number
HiByte
LoByte
CRC
LoByte
HiByte
2.4.2 Function 101:
Write Registers32
The ModBus operator supports fieldbus supervising. Two operator parameters configure
this function. Watchdog_Inhibit defines several events that reset the fieldbus watchdog.
Watchdog_Activation serves for activating the watchdog functions with the first
occurence of certain events. The effect of the timeout of the Watchdog timer is adjusted
via parameter Pn.05. Parameter Pn.6 determines the Watchdog time. For more information
see parameter description below and in the application manual of the used inverter
control.
2.5 Fieldbus Watchdog
ModBus Functions

KEB F5 COMBICOM ModBus Specifications
