DISASSEMBLY INSTRUCTIONS INDOOR UNIT
Remove the left end connection. Hold the end of
connection rod with left hand. Hold the horizontal
louver with right hand to separate connection rod
and horizontal louver.
Remove the horizontal louver along the center axle.
NOTE: During operation, install the left end of the
horizontal louver first then install the right end.
Once installed, restart the unit until the louver is reset.
Once louver is reset, you can operate the unit.
Remove 4 screws on front case and electric box
cover with screwdriver.
Remove electric box cover.
1
2
3
4
5
