KEEWAY HURRICANE Maintenance Manual

112
TIGHTENTING TORQUE O F SCREW THREAD PARTS
ENGINE
ITEM
N．M
Cylinder guide cover tapping screw
1-4
Fan guide cover lock bolt
10-12
Cylinder cover locknut
15-18
Spark plug
15-18
Inlet pipe lock bolt 10-12
Cooling fan impeller lock screw
10-12
Flywheel lock bolt
45-50
Magneto stator coil lock screw
10-12
Magneto exciting lock screw
3-5
Oil pump lock screw
5-9
Right crankcase lock bolt
10-12
Bearing press board lock bolt
10-12
Cylinder double head bolt
15-18
Motor tightening bolt
10-12
Left crankcase cover lock screw
10-12
Left crankcase cover lock bolt
10-12
Main drive wheel face locknut
35-38
Driven wheel face locknut
35-38
Driven wheel face clutch locknut
55-60
Exceeding clutch outside lock screw
10-12
Electrical start idle press board screw
10-12
Gearcase lock bolt
10-12
Left crankcase discharging oil hole lock bolt
22-25
Left crankcase positioning pin shaft locknut
18-22

KEEWAY HURRICANE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Height	1120 mm
Engine Type	Single cylinder, 4-stroke
Max Torque	9.2 Nm @ 6500 rpm
Cooling System	Air cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
