96
REAR WHEEL AND BRAKE
1. Tire 130/70-12
2.rear rim assy.
3.
brake pad kit
assy.
4.
brake pad kit
spring
5.
rear brake
tension
6. rear indicator
7. anti-dust cover
8.
rear brake
camshaft
9. bolt M6Χ30
10.valve
11.nut M16Χ1.5
12. rear brake arm
13. valve cap
