KEEWAY HURRICANE Maintenance Manual

94
Reassembly and remounting
reassemble and remount the steering stem, handlebar and front
fork in the reverse order of disassembly andremoval, and also
carry out the following steps.
Install the right left suspension arms.
Steel ball
Apply grease when installing the upper and lower steel balls.
QTY：upper ：21
lower ：21
Tighten the steering outer race with special tool, then extrude it
1/8-1/4round.
NOTE：adjustment will vary from scooter to scooter. Be sure that the steering turns smoothly and easily, left to
right.
□ install a locknut by installing locknut and anti-dust cover
□ screw locknut with special tool, and adjust front fork bearing to
get smooth turning.

KEEWAY HURRICANE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Height	1120 mm
Engine Type	Single cylinder, 4-stroke
Max Torque	9.2 Nm @ 6500 rpm
Cooling System	Air cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
