KEEWAY HURRICANE Maintenance Manual

82
Front wheel
1. front rim
2. middle bushing
3. oil seal
4. roller bearing GB6201-2RS
5. tire
6. valve mouth
7. nut GB6817
8. front shaft
9. front wheel left bushing
10. gearcase
11. valve mouth cap
remove
·Remove the front brake caliper① by removing the mounting
bolts.
NOTE：Do not operate the front brake lever while dismounting caliper
·remove mounting bolt③
·remove the left decorating cover④ and right one⑤.
·remove under front fender⑥
·support the scooter by jack or wood
shelf.
·Remove front wheel by removing
front axle shaft.
①
①①
①
②
②②
②
③
③③
③
⑤
⑤⑤
⑤
④
④④
④
⑥
⑥⑥
⑥

KEEWAY HURRICANE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Height	1120 mm
Engine Type	Single cylinder, 4-stroke
Max Torque	9.2 Nm @ 6500 rpm
Cooling System	Air cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
